SIKLU MultiHaul - Terragraph Base Unit, TG-Node366
koncwdjicnwdcwdce
Technical data
Aggregate throughput up to 16Gbps till 300m of distance

- Frequency: 57-66GHz (free V-Band spectrum)

- Connects devices to PtMP, PtP, and Self-Backhaul Mesh networks

- Coverage: Horizontal 360° - 4x 90° per sector, Vertical 50°

- Maximum capacity > 3,800Mbps per sector, > 7,600Mbps using licensed CB2

- Interfaces: 1x RJ-45 1GbE, 1x RJ-45 1/2.5/5/10GbE, 1x SFP + 10GbE and USB ports

- AES 128-bit security encryption


It is an ideal solution for densely populated areas. It can be used in a wide range of applications as GTTH (Gigabit to the Home), Security, Smart, Business and Safe city networks, Permanent wireless redundant access and Wi-Fi Backhaul.

koncwdjicnwdcwdce
Aggregate throughput up to 16Gbps till 300m of distance

- Frequency: 57-66GHz (free V-Band spectrum)

- Connects devices to PtMP, PtP, and Self-Backhaul Mesh networks

- Coverage: Horizontal 360° - 4x 90° per sector, Vertical 50°

- Maximum capacity > 3,800Mbps per sector, > 7,600Mbps using licensed CB2

- Interfaces: 1x RJ-45 1GbE, 1x RJ-45 1/2.5/5/10GbE, 1x SFP + 10GbE and USB ports

- AES 128-bit security encryption


It is an ideal solution for densely populated areas. It can be used in a wide range of applications as GTTH (Gigabit to the Home), Security, Smart, Business and Safe city networks, Permanent wireless redundant access and Wi-Fi Backhaul.

Technical data
SIKLU MultiHaul - Terragraph Terminal Unit, TG TU-T265
TG TU-T265
Technical data
Up to 4.6Gbps till 300m of distance

- Frequency: 57-66GHz (free V-Band spectrum)

- Connect devices to PtMP and PtP networks

- Coverage: 90° Horizontal, 50° Vertical

- Maximum capacity: 4.600Mbps

- Interfaces: T265-CCP: 1x RJ-45 1GbE - 35W PoE-Out, 1x RJ-45 1/2,5GbE - PoE-In, 1x SFP 10GbE

                   T265-CNN: 1x RJ-45 1/2,5GbE - PoE-In

- AES 128-bit security encryption


Together with the TG Node366 is the first Terragraph solution in the world. It presents a Point to Multi-Point TG solution suitable for GTTH use in densely populated areas, fixed 5G wireless access, SmartCity, Security, MDU, Enterprise applications and Smaller closed networks. Also as a Wi-Fi Hotspot Backhaul access point.

TG TU-T265
Up to 4.6Gbps till 300m of distance

- Frequency: 57-66GHz (free V-Band spectrum)

- Connect devices to PtMP and PtP networks

- Coverage: 90° Horizontal, 50° Vertical

- Maximum capacity: 4.600Mbps

- Interfaces: T265-CCP: 1x RJ-45 1GbE - 35W PoE-Out, 1x RJ-45 1/2,5GbE - PoE-In, 1x SFP 10GbE

                   T265-CNN: 1x RJ-45 1/2,5GbE - PoE-In

- AES 128-bit security encryption


Together with the TG Node366 is the first Terragraph solution in the world. It presents a Point to Multi-Point TG solution suitable for GTTH use in densely populated areas, fixed 5G wireless access, SmartCity, Security, MDU, Enterprise applications and Smaller closed networks. Also as a Wi-Fi Hotspot Backhaul access point.

Technical data
SIKLU MultiHaul – PtMP Base Unit (BU), Terminal Unit (TU)
siklu-MultiHaul-PtMP
Technical data
Up to 1.8Gbps till 350m of distance

- Frequency: 57-64GHz (free V-Band spectrum)

- Connects devices to PtMP and PtP networks

- Coverage: 90° Horizontal, 20° Vertical

- Maximum capacity: BU: 500Mbps or 1,800Mbps using an additional license                                  TU: 100Mbps or 1,000Mbps using an additional license

- Interfaces: BU: 2x RJ-45 100/1,000 Base-T, 1x SFP 1/2,5GbE ports                     TU-200-CCS: 2x RJ-45 100/1,000 Base-T, 1x SFP 1GbE ports                     TU-200-CCC: 3x RJ-45 100/1,000 Base-T ports

                    TU-200-CNN: 1x RJ-45 100/1,000 Base-T port

- AES 128-bit and 256-bit security encryption


It is an ideal Point to Multi-Point connection. An individual Base Unit can be connected to up to 8 Terminal Units. Radio links are synchronized automatically at startup. With the Management and Control Center software, we can remotely control the flow of data and by using additional licenses increase transfer speeds to any client.

siklu-MultiHaul-PtMP
Up to 1.8Gbps till 350m of distance

- Frequency: 57-64GHz (free V-Band spectrum)

- Connects devices to PtMP and PtP networks

- Coverage: 90° Horizontal, 20° Vertical

- Maximum capacity: BU: 500Mbps or 1,800Mbps using an additional license                                  TU: 100Mbps or 1,000Mbps using an additional license

- Interfaces: BU: 2x RJ-45 100/1,000 Base-T, 1x SFP 1/2,5GbE ports                     TU-200-CCS: 2x RJ-45 100/1,000 Base-T, 1x SFP 1GbE ports                     TU-200-CCC: 3x RJ-45 100/1,000 Base-T ports

                    TU-200-CNN: 1x RJ-45 100/1,000 Base-T port

- AES 128-bit and 256-bit security encryption


It is an ideal Point to Multi-Point connection. An individual Base Unit can be connected to up to 8 Terminal Units. Radio links are synchronized automatically at startup. With the Management and Control Center software, we can remotely control the flow of data and by using additional licenses increase transfer speeds to any client.

Technical data
SIKLU MultiHaul – cTU-201
cTU_GA_landing-page_01-1024x520-11111
Technical data
Same Features and Throughput as MultiHaul TU till 200m of distance in a Form factor 85% Smaller

- Frequency: 57-64GHz (free V-Band spectrum)

- Connects devices to PtMP and PtP networks

- Coverage: 90° Horizontal, 20° Vertical

- Maximum capacity 100Mbps or 1,000Mbps using an additional license

- Interfaces: 1x RJ-45 GbE 100/1,000 Base-T port

- AES 128-bit security encryption


A palm-sized Point to Multi-Point compact radio link is the ideal solution in urban areas. It automatically synchronizes with the corresponding Base Unit at startup. In case of any BU failure, it can be redundantly re-connected to the neighboring one, if it is in his LOS.

cTU_GA_landing-page_01-1024x520-11111
Same Features and Throughput as MultiHaul TU till 200m of distance in a Form factor 85% Smaller

- Frequency: 57-64GHz (free V-Band spectrum)

- Connects devices to PtMP and PtP networks

- Coverage: 90° Horizontal, 20° Vertical

- Maximum capacity 100Mbps or 1,000Mbps using an additional license

- Interfaces: 1x RJ-45 GbE 100/1,000 Base-T port

- AES 128-bit security encryption


A palm-sized Point to Multi-Point compact radio link is the ideal solution in urban areas. It automatically synchronizes with the corresponding Base Unit at startup. In case of any BU failure, it can be redundantly re-connected to the neighboring one, if it is in his LOS.

Technical data
SIKLU EtherHaul – 400 series
siklu-400-cnn
Technical data
Up to 1.8Gbps Aggregated, 1Gbps Full duplex till 400m of distance

- Frequency: 57-64GHz (free V-Band spectrum), FDD/TDD

- Connects devices to PtP networks

- Coverage: 90° Horizontal, 20° Vertical

- Maximum capacity 1Gbps Full duplex, 1.8Gbps Aggregated

- Interfaces: MPL-400-CCS: 2x RJ-45 100/1,000 Base-T, 1x SFP 1GbE ports                    MPL-400-CCC: 3x RJ-45 100/1,000 Base-T ports

                   MPL-400-CNN: 1x RJ-45 100/1,000 Base-T port

- AES 128-bit security encryption


It is an ideal Point to Point connection. It can be connected beside Base Unit or just be used for any kind of short distance connections. Radio links are synchronized automatically at startup. It can be used in applications connecting Video surveillance devices and systems, Smart & Safe cities, public Wi-Fi & Enterprise Backhaul.

siklu-400-cnn
Up to 1.8Gbps Aggregated, 1Gbps Full duplex till 400m of distance

- Frequency: 57-64GHz (free V-Band spectrum), FDD/TDD

- Connects devices to PtP networks

- Coverage: 90° Horizontal, 20° Vertical

- Maximum capacity 1Gbps Full duplex, 1.8Gbps Aggregated

- Interfaces: MPL-400-CCS: 2x RJ-45 100/1,000 Base-T, 1x SFP 1GbE ports                    MPL-400-CCC: 3x RJ-45 100/1,000 Base-T ports

                   MPL-400-CNN: 1x RJ-45 100/1,000 Base-T port

- AES 128-bit security encryption


It is an ideal Point to Point connection. It can be connected beside Base Unit or just be used for any kind of short distance connections. Radio links are synchronized automatically at startup. It can be used in applications connecting Video surveillance devices and systems, Smart & Safe cities, public Wi-Fi & Enterprise Backhaul.

Technical data
SIKLU EtherHaul – 600 series
Siklu-Siklu-EtherHaul-EH-500-EH-600
Technical data
Up to 1Gbps till 1.3km of distance

- Frequency: 57-66GHz (free V-Band spectrum), TDD

- Connects devices to PtP networks

- Maximum capacity 1,000Mbps

- Interfaces: 3x RJ-45 GbE ports

- Antenna size: 16cm

- AES 128-bit and 256-bit security encryption


It is a great choice for Point to Point solutions. With its small size, it represents easy and fast installation on any street infrastructure. It can be used in applications connecting Video surveillance devices and systems, Wi-Fi access points and GTTH (Gigabit to the Home).

Siklu-Siklu-EtherHaul-EH-500-EH-600
Up to 1Gbps till 1.3km of distance

- Frequency: 57-66GHz (free V-Band spectrum), TDD

- Connects devices to PtP networks

- Maximum capacity 1,000Mbps

- Interfaces: 3x RJ-45 GbE ports

- Antenna size: 16cm

- AES 128-bit and 256-bit security encryption


It is a great choice for Point to Point solutions. With its small size, it represents easy and fast installation on any street infrastructure. It can be used in applications connecting Video surveillance devices and systems, Wi-Fi access points and GTTH (Gigabit to the Home).

Technical data
SIKLU EtherHaul – 700 series
siklu-etherhaul-710tx-radio-unit-with-int-0-5ft-antenna-1-gbps-s-half-duplex-3x-gb-lan-poe-power-supply-big_ies548538
Technical data
Up to 1Gbps till 2.6km of distance with 65cm antenna

- Frequency: 71-76GHz (low licensed E-Band spectrum fee), TDD

- Connects devices to PtP networks

- Maximum capacity: 700TX - 200Mbps, 710T/TX - 1,000Mbps

- Interfaces: 3x RJ-45 GbE ports

- Antenna size: 16cm, 31cm or 65cm

- AES 128-bit and 256-bit security encryption


It is a great choice for Point to Point solutions. With its small size, it represents easy and fast installation on any street infrastructure. It can be used in applications connecting Video surveillance devices and systems, Wi-Fi access points and GTTH (Gigabit to the Home).

siklu-etherhaul-710tx-radio-unit-with-int-0-5ft-antenna-1-gbps-s-half-duplex-3x-gb-lan-poe-power-supply-big_ies548538
Up to 1Gbps till 2.6km of distance with 65cm antenna

- Frequency: 71-76GHz (low licensed E-Band spectrum fee), TDD

- Connects devices to PtP networks

- Maximum capacity: 700TX - 200Mbps, 710T/TX - 1,000Mbps

- Interfaces: 3x RJ-45 GbE ports

- Antenna size: 16cm, 31cm or 65cm

- AES 128-bit and 256-bit security encryption


It is a great choice for Point to Point solutions. With its small size, it represents easy and fast installation on any street infrastructure. It can be used in applications connecting Video surveillance devices and systems, Wi-Fi access points and GTTH (Gigabit to the Home).

Technical data
SIKLU EtherHaul – 1200FX
E-Band-Gray-Background1
Technical data
Up to 1Gbps till 2.6km of distance with 65cm antenna

- Frequency: 71-76/81-86GHz (low licensed E-Band spectrum fee), FDD

- Connects devices to PtP networks

- Maximum capacity 1,000Mbps Full duplex

- Interfaces: 2x GbE 1,000 Base-T ports

- Antenna size: 31cm or 65cm

- AES 128-bit and 256-bit security encryption


It represents the next generation of wireless Ethernet networks. Using FDD, they are used in applications for Optical network extension, LAN to LAN connectivity, wireless Business and Security networks and for Temporary installations.

E-Band-Gray-Background1
Up to 1Gbps till 2.6km of distance with 65cm antenna

- Frequency: 71-76/81-86GHz (low licensed E-Band spectrum fee), FDD

- Connects devices to PtP networks

- Maximum capacity 1,000Mbps Full duplex

- Interfaces: 2x GbE 1,000 Base-T ports

- Antenna size: 31cm or 65cm

- AES 128-bit and 256-bit security encryption


It represents the next generation of wireless Ethernet networks. Using FDD, they are used in applications for Optical network extension, LAN to LAN connectivity, wireless Business and Security networks and for Temporary installations.

Technical data
SIKLU EtherHaul – 2X00 series
117950_1__siklu_eh2500-2
Technical data
Up to 2Gbps till 2 to 6km distance with 65cm antenna

- Frequency: 71-76/81-86GHz (low licensed E-Band spectrum fee), FDD

- Connects devices to PtP networks

- Maximum capacity 2,000Mbps Full duplex

- Range depends on model, antenna size and weather conditions

- Interfaces: 4x RJ-45 GbE, 2x RJ-45 and 2x SFP SMF/MMF ports

- Antenna size: 16cm, 31cm or 65cm

- AES 128-bit and 256-bit security encryption


The 2X00 series delivers the same performance as fiber optics. It is used in applications for Smart City and Video Surveillance networks, GTTH (Gigabit to the Home) and LAN to LAN connectivity within a range of 2 to 6km.

117950_1__siklu_eh2500-2
Up to 2Gbps till 2 to 6km distance with 65cm antenna

- Frequency: 71-76/81-86GHz (low licensed E-Band spectrum fee), FDD

- Connects devices to PtP networks

- Maximum capacity 2,000Mbps Full duplex

- Range depends on model, antenna size and weather conditions

- Interfaces: 4x RJ-45 GbE, 2x RJ-45 and 2x SFP SMF/MMF ports

- Antenna size: 16cm, 31cm or 65cm

- AES 128-bit and 256-bit security encryption


The 2X00 series delivers the same performance as fiber optics. It is used in applications for Smart City and Video Surveillance networks, GTTH (Gigabit to the Home) and LAN to LAN connectivity within a range of 2 to 6km.

Technical data
SIKLU EtherHaul - 5500FD
